Brand CAM Model ZPA1612L/1A-B
Capacity 1600kg / 600mm Code CAM-ZPA
Specification Push-Pull fork

Push-pull with sheet retainer (ZPA)
By means of slipsheets instead of pallets, this attachment can push and pull goods safely and efficiently. It can improve production efficiency and save costs. It can be used in electronics, food, light industry and other industries.

Characteristics

  • Loading and unloading goods can be done without pallets
  • Protected hydraulics
  • Simplified hydraulic circuit

Technical details

  • 1 hydraulic function
  • L28 – Extendable range of the push-pull

Technical details:

Model Capacity W88-W99  ISO 2328 W38 x H38  W29 x L29  L28  W6  Weight
kg/mm  mm    mm  mm  mm  mm  kg
Quick Forks mounting type
ZPA1612L-1A/B  1600/600  1020 – 1170  2A  1015 x 1000  455 x 1220 1270 820 475
ZPA1612L-1A/B  1600/600  1020 – 1170  2A/3A  1015 x 1000  455 x 1220 1270 820 475
ZPA1612L-1B  1600/600  1020 – 1170  3A  1015 x 1000  455 x 1220 1270 820 482
ZPA2012L-1A  2000/600  1020 – 1170  2A  1015 x 1000  455 x 1220 1270 820 489
Standard type with sideshifter
ZPA1612-1SA  1600/600  1020 – 1120 2A 1015 x 1000 455 x 1220 1270 920 659
ZPA1612-3SA  1600/600  1020 – 1120 2A 1015 x 1000 380 x 1220 1270 920 659
ZPA2012-1SA  2000/600  1020 – 1120 2A 1015 x 1000 455 x 1220 1270 920 675
